Lead smelting pot The material is Q245R boiler steel plate (δ=25mm), and the bottom of lead kettle is hemispherical body. Lead pump is used to transport from refining kettle to alloy configuration kettle. Chemical composition and mechanical property of Q245R。 Cold rolled steel plates usually have a thickness of 40 to 50mm, which can be produced according to the drawing; A lead pot is a container made of circular iron plate barrels and thick welded heads, or made by one-time stamping and welding of the pot mouth, with a capacity ranging from 3T-120T, welded process can be customized size for you . Cold rolled steel plates usually have a thickness of 40 to 50mm, which can be produced according to the drawing;
LuFeng is mainly engaged in the development, manufacturing, installation and debugging of mining, smelting and construction machinery. Now the main productions are smelting equipment and complete set of equipment, such as: smelting furnace , automatic production line of lead /Aluminum /copper (zinc) ingot casting machine, anode plate casting machine, cathode production machine, crusher, slag casting machine, mixer, lead pump, lead pot and non-standard equipment.
delivery 2T crude lead ingot molds to clients today , it is 2T of capacity of cast, this molds weight is 1T per unit .
Rotary smelting furnace A rotary furnace is a type of blast furnace, whose body is an inclined cylindrical container that can rotate. The principle of rotary furnace is to use the effect of high temperature and high-speed Redox to mix ore and coke together, rapidly heat and melt in the furnace, and separate metal and waste slag. The internal parts of the rotary furnace are divided into different areas, with the top layer being the combustion zone, where coke and oxygen react to produce high-temperature and high-pressure gas flow. The gas flows downwards and enters the reduction zone. The ore and coke undergo a reduction reaction in the reduction zone, and the metal is reduced out. The metal flows downwards along the furnace barrel and finally reaches the slag area, where it is separated from the waste slag. The rotary furnace has the advantages of high production capacity and high melting efficiency, and can melt various metal materials such as iron, steel, and alloys. In the steel industry, rotary furnaces have become one of the main steelmaking equipment, widely used in fields such as steelmaking, ironmaking, and scrap recovery. Lead scraps, Lead grid, Lead acid battery scrap, adaptable to different raw materials. The Lead melting rotary furnace consists of a rotary host, a fire-resistant furnace lining, a combustion system, a hydraulic system, a Ring gear transmission system and a flue system. Both charging and discharging pass through the furnace mouth installed with a furnace door. During charging and discharging, the furnace door installed with a burner can be opened. Auxiliary machines are equipped with supporting automatic feeding machine, automatic slag (soup) bag and slag raking machine, and automatic ingot casting and stacking machine. Through these supporting equipment, the automatic operation of the whole process can be realized. Details include: - Refractory Material of Chrome-Magnesium basis - air-fuel burner or Oxy-fuel burner or Heavy oil burner - Feeding door opening through local control panel and through remote control - Door operation system with hydraulic unit; - Rotation system 0 - 1 rpm with variable speed driver (by VFD)
Residual pole scrubber In the process of electrolytic refining of lead by residual electrode scrubber, the metal lead loses electrons in the anode and becomes lead ions which enter the electrolyte, in addition to a small part of the impurities in the anode and lead dissolved in the electrolyte, the vast majority of insoluble and adhere to the anode surface to form anode slime. The anode slime contains a lot of lead, antimony, bismuth and precious metals such as gold and silver, so the attached anode slime and residual acid must be cleaned and recycled to reduce repeated smelting. At present, there are three kinds of washing equipment in China: horizontal residual electrode washing machine, vertical residual electrode washing machine, rotary residual electrode washing machine.
customized anode plate hanger for clients
